8048RF Feeder Conveyor

8048RF Feeder Conveyor

The newly designed Tesab 8048RF is the latest offering as a feeder stacker. It comprises of a large feeder hopper that transfers material onto an 80ft conveyor and provides a rear, low level option to operators.

Designed to allow operators to stockpile/ transfer material it eliminates double handling of materials.

The unit can also be compacted for transport on one low loader for easy site to site transport.

Key Features

100KW (127HP) engine

Dual hydraulic main drive system

Hydraulically adjustable discharge height up to 10m

4m tracks for superior maneuverability and stability

Fuel efficient Hydraulics system

User Friendly Hydraulic Controls

Hydraulic folding heading section for transport minimizing setup time


127 Hp (100 kW)

24,500kg approx. (54,013 lbs)

10m³ (13 yd³)

880 TPH (800 metric TPH)

Height  3.2m (10′ 6″)

Width  2.9m (9′ 5″)

Length  19.3m (38′ 7″)

Height 10.2m (33′ 7″)

Length 26.1m (85′ 10″)
